Our CANBUS PRO Series Plug-N-Play harness completely replaces your old OEM engine harness so you can forget about those electrical gremlins, while retaining critical speedometer, tachometer and other factory functions.
This harness is specifically engineered for a BMW 5 Series E39 1998-2003 with the Turbo2JZGTE VVTi or Non-Turbo 2JZGE VVTi engine swap. It was developed in house on an actual 2JZ VVTi engine to ensure a perfect fit to all engine connections.
Build your perfect harness by selecting from the available options to the right, and as always - if you have any questions, please reach out to us.
BMW E39 2JZ NOTES
Conversion from stock electronic Drive-By-Wire throttle pedal to cable pedal is REQUIRED
Any VVTI 2JZGTE from JDM Aristo model years 1997-2002
Any VVTI 2JZGTE from JDM Supra RZ model years 1997-2002
Any VVTI 2JZGE from JDM Soarer JZZ31 model years 1997-2000
Any VVTI 2JZGE from JDM Aristo JZS160 model years 1997-2004
Any VVTI 2JZGE from USDM SC300 JZZ31 model years 1998-2001
Any VVTI 2JZGE from USDM IS300 JCE10 model years 2001-2005
Any VVTI 2JZGE from USDM GS300 JZS160 model years 1998-2005
Oval Alternator, New Style Starter, and Plastic Coolant & Oil pressure connector supplied by default. If you need different connectors for these please leave a Note / Comment when checking out.
Standard – VVTi batched ignition (chip and coils) are supplied, but sequential NON VVTi ignition is available as an option.
For GM/LQ9 coils – upgrade should be used with an aftermarket ECU and run sequentially. OEM ECUs require IGF signal produced by the ignition chip. When the chip is removed for LQ9 coil installation, an aftermarket ECU or IGF simulator box is required.
CHASSIS: BMW 5 Series E39 1998-2003 USING CABLE THROTTLE CONVERSION ONLY
BMW 5 Series E39 1998-2003
Factory Speedometer functions by utilizing the ABS system outputs. As long as this system is properly functional, the speedometer will remain accurate.
Factory Tachometer remains functional via CANBUS.
A/C wiring utilizes the stock BMW fuse box AC relay and wiring. The provided AC compressor connector must be wired to the chassis’ output AC signal wire.
Retains functional alternator charge display, oil pressure display, coolant temperature display, reverse lights and wipers.
Factory cooling fans remain functional if that option is selected.
PRO-SERIES HARNESS TECHNICAL SPECS
Plug and Play – simple and efficient
NO CORE HARNESS or additional wiring required
OEM wire colors used, where applicable
All sensor signal connection use EM shielded wires
Super-High Temp Fireproof fiberglass loom used on knock sensor, O2 sensor & transmission branches located in hot areas. (-40°C/-40°F to +450°C/+845°F operating temperature)
Point-to-Point continuity tested on every wire
Constructed using exact OEM connectors and seals
Made with high temp TXL wire with adhesive shrink tubing (-40°C/-40°F to +125°C/+257°F operating temperature)
Wrapped in lightweight nylon loom (-94°C/-137°F to +125°C/+257°F operating temperature)
Includes a charge harness and improved grounds
Fully tested after production for an easy plug-and-play installation
PRO-SERIES HARNESS INCLUDES
Harness fully redesigned with optimized & improved power and ground routing
Supplied with 5 Fused Relays in a weather-tight sealed Bussmann Box
Relays provided: Ignition, Fuel Pump, Fan1, Fan2 & A/C relay (if not using A/C can be used for aux function like oil/diff cooler fan etc)
Main Engine and Transmission one-piece tucked harness
Alternator charge cable built into the main harness
Knock sensor sub-harness connector
MAFS connector
MAP sensor connector
Intake Air Temp connector
TPS connector
8x Injector connectors
Integrated Bank 1 and Bank 2 Coil Harnesses in the OEM location – no sub-harnesses required
Oil Pressure gauge connector
Proper gauge wiring support for Dual 30 Amp PCM-controlled electric cooling fans
Cam sensor connector
Crank sensor connector
Bank 1 and Bank 2 FRONT Oxygen sensor connectors (High Temp shielding)
1 x Ground ring terminal
Idle air connector
ECT sensor connector and cluster coolant temp switch connector
Reverse lights sensor connector
Speed sensor connector
Reverse Lockout connector
Skip Shift connector
Alternator connector
Starter signal/start connector
A/C Wiring is available as an option. Please note that adding A/C to an LS2 is not easy and will require custom lines and sensor installation. Wiring Specialties will provide a wiring sub-harness needed for operating the A/C system ONLY
OBD2 Communication connector
Printable install instructions with pictures
Turn Key ENGINE START Guarantee
Tech support for our customers 7 days a week
FAQ & OTHER DETAILS
Alternator Charge Cable - This item ties the starter/battery directly to the Alternator output, which allows the improved power routing on our harness to eliminate the wire running from the alternator to the fusebox and/or battery while still charging the battery normally.
Grounding Kit - Our Kit ties a number if engine components to the body of the car and ensures that you will not have issues resulting from poor grounds. The Grounding Kit utilizes Ultra High temp fiberglass sleeving to allow installation under or around exhaust components. Very flexible mounting options allow you to connect the block, head, battery tray, alternator case and chassis to completely eliminate all grounding issues.
Speedo Signal Conditioning - The Dakota Digital SGI-5 unit for Speed can 'condition' the signal to compensate for cross-platform swaps. If the Option exists to ADD the unit on the harness page for your swap, then you need it for proper speedo operation. Please note that some transmissions (350z, BMW ZF and S15 Silvia for example) do not have a speed sensor and will require a non-harness based solution like a GPS speedo.
Plug-n-Play vs Universal - Plug-n-Play harnesses connect to your car's underhood fuse box for power and to connectors under the dash for gauges etc. Universal harnesses do not need an underhood fusebox to connect to and the wiring for gauges and warning lights is provided as a 'flying lead' which are bare wires labeled with their function.
Right Hand Drive (RHD) Conversions - If you used ALL the stock LHD chassis connectors for your RHD swap, order the LHD version of the harness. If you used ALL the clip/swap RHD chassis connectors, order the RHD version of the harness. If you used a combination of LHD and RHD chassis connectors, please contact us as our harnesses will need modification.
Don't See It? - If you have injectors, throttle body, coilpacks or any other item that you do not see on the Options offerings, please contact us. Chances are we can do it!
Battery Cables / Battery Relocation - The battery must be connected to the starter, so you need a battery cable from the positive battery terminal to the starter main power lug. Typically this positive battery cable also powers up the main under hood fusebox, which runs many of the non-engine items on your car like interior lights, dash power and headlights/taillights. Please make sure you have prepared for this as each install is different.
2JZGTE / 2JZGE VVTi Wiring Harness for BMW E39 - CANBUS PRO SERIES
SKU:
WRS-PRO2JZVVTI-E39
Shipping:
Calculated at Checkout
Select one option for all of the fields below
Share This Article
Product Description
Our CANBUS PRO Series Plug-N-Play harness completely replaces your old OEM engine harness so you can forget about those electrical gremlins, while retaining critical speedometer, tachometer and other factory functions.
This harness is specifically engineered for a BMW 5 Series E39 1998-2003 with the Turbo2JZGTE VVTi or Non-Turbo 2JZGE VVTi engine swap. It was developed in house on an actual 2JZ VVTi engine to ensure a perfect fit to all engine connections.
Build your perfect harness by selecting from the available options to the right, and as always - if you have any questions, please reach out to us.
BMW E39 2JZ NOTES
Conversion from stock electronic Drive-By-Wire throttle pedal to cable pedal is REQUIRED
Any VVTI 2JZGTE from JDM Aristo model years 1997-2002
Any VVTI 2JZGTE from JDM Supra RZ model years 1997-2002
Any VVTI 2JZGE from JDM Soarer JZZ31 model years 1997-2000
Any VVTI 2JZGE from JDM Aristo JZS160 model years 1997-2004
Any VVTI 2JZGE from USDM SC300 JZZ31 model years 1998-2001
Any VVTI 2JZGE from USDM IS300 JCE10 model years 2001-2005
Any VVTI 2JZGE from USDM GS300 JZS160 model years 1998-2005
Oval Alternator, New Style Starter, and Plastic Coolant & Oil pressure connector supplied by default. If you need different connectors for these please leave a Note / Comment when checking out.
Standard – VVTi batched ignition (chip and coils) are supplied, but sequential NON VVTi ignition is available as an option.
For GM/LQ9 coils – upgrade should be used with an aftermarket ECU and run sequentially. OEM ECUs require IGF signal produced by the ignition chip. When the chip is removed for LQ9 coil installation, an aftermarket ECU or IGF simulator box is required.
CHASSIS: BMW 5 Series E39 1998-2003 USING CABLE THROTTLE CONVERSION ONLY
BMW 5 Series E39 1998-2003
Factory Speedometer functions by utilizing the ABS system outputs. As long as this system is properly functional, the speedometer will remain accurate.
Factory Tachometer remains functional via CANBUS.
A/C wiring utilizes the stock BMW fuse box AC relay and wiring. The provided AC compressor connector must be wired to the chassis’ output AC signal wire.
Retains functional alternator charge display, oil pressure display, coolant temperature display, reverse lights and wipers.
Factory cooling fans remain functional if that option is selected.
PRO-SERIES HARNESS TECHNICAL SPECS
Plug and Play – simple and efficient
NO CORE HARNESS or additional wiring required
OEM wire colors used, where applicable
All sensor signal connection use EM shielded wires
Super-High Temp Fireproof fiberglass loom used on knock sensor, O2 sensor & transmission branches located in hot areas. (-40°C/-40°F to +450°C/+845°F operating temperature)
Point-to-Point continuity tested on every wire
Constructed using exact OEM connectors and seals
Made with high temp TXL wire with adhesive shrink tubing (-40°C/-40°F to +125°C/+257°F operating temperature)
Wrapped in lightweight nylon loom (-94°C/-137°F to +125°C/+257°F operating temperature)
Includes a charge harness and improved grounds
Fully tested after production for an easy plug-and-play installation
PRO-SERIES HARNESS INCLUDES
Harness fully redesigned with optimized & improved power and ground routing
Supplied with 5 Fused Relays in a weather-tight sealed Bussmann Box
Relays provided: Ignition, Fuel Pump, Fan1, Fan2 & A/C relay (if not using A/C can be used for aux function like oil/diff cooler fan etc)
Main Engine and Transmission one-piece tucked harness
Alternator charge cable built into the main harness
Knock sensor sub-harness connector
MAFS connector
MAP sensor connector
Intake Air Temp connector
TPS connector
8x Injector connectors
Integrated Bank 1 and Bank 2 Coil Harnesses in the OEM location – no sub-harnesses required
Oil Pressure gauge connector
Proper gauge wiring support for Dual 30 Amp PCM-controlled electric cooling fans
Cam sensor connector
Crank sensor connector
Bank 1 and Bank 2 FRONT Oxygen sensor connectors (High Temp shielding)
1 x Ground ring terminal
Idle air connector
ECT sensor connector and cluster coolant temp switch connector
Reverse lights sensor connector
Speed sensor connector
Reverse Lockout connector
Skip Shift connector
Alternator connector
Starter signal/start connector
A/C Wiring is available as an option. Please note that adding A/C to an LS2 is not easy and will require custom lines and sensor installation. Wiring Specialties will provide a wiring sub-harness needed for operating the A/C system ONLY
OBD2 Communication connector
Printable install instructions with pictures
Turn Key ENGINE START Guarantee
Tech support for our customers 7 days a week
FAQ & OTHER DETAILS
Alternator Charge Cable - This item ties the starter/battery directly to the Alternator output, which allows the improved power routing on our harness to eliminate the wire running from the alternator to the fusebox and/or battery while still charging the battery normally.
Grounding Kit - Our Kit ties a number if engine components to the body of the car and ensures that you will not have issues resulting from poor grounds. The Grounding Kit utilizes Ultra High temp fiberglass sleeving to allow installation under or around exhaust components. Very flexible mounting options allow you to connect the block, head, battery tray, alternator case and chassis to completely eliminate all grounding issues.
Speedo Signal Conditioning - The Dakota Digital SGI-5 unit for Speed can 'condition' the signal to compensate for cross-platform swaps. If the Option exists to ADD the unit on the harness page for your swap, then you need it for proper speedo operation. Please note that some transmissions (350z, BMW ZF and S15 Silvia for example) do not have a speed sensor and will require a non-harness based solution like a GPS speedo.
Plug-n-Play vs Universal - Plug-n-Play harnesses connect to your car's underhood fuse box for power and to connectors under the dash for gauges etc. Universal harnesses do not need an underhood fusebox to connect to and the wiring for gauges and warning lights is provided as a 'flying lead' which are bare wires labeled with their function.
Right Hand Drive (RHD) Conversions - If you used ALL the stock LHD chassis connectors for your RHD swap, order the LHD version of the harness. If you used ALL the clip/swap RHD chassis connectors, order the RHD version of the harness. If you used a combination of LHD and RHD chassis connectors, please contact us as our harnesses will need modification.
Don't See It? - If you have injectors, throttle body, coilpacks or any other item that you do not see on the Options offerings, please contact us. Chances are we can do it!
Battery Cables / Battery Relocation - The battery must be connected to the starter, so you need a battery cable from the positive battery terminal to the starter main power lug. Typically this positive battery cable also powers up the main under hood fusebox, which runs many of the non-engine items on your car like interior lights, dash power and headlights/taillights. Please make sure you have prepared for this as each install is different.
